GE IS220PTURH1A Turbine Specific Primary Trip Modules
Description
| Manufacture | GE |
| Model | IS220PTURH1A |
| Ordering information | IS220PTURH1A |
| Catalog | Mark Vie |
| Description | GE IS220PTURH1A Turbine Specific Primary Trip Modules |
| Origin | United States (US) |
| HS Code | 85389091 |
| Dimension | 16cm*16cm*12cm |
| Weight | 0.8kg |
Details
PTUR and YTUR Turbine Specific Primary Trip
Modules
The following hardware combinations are approved for use in hazardous locations:
• MarkVIeTurbineSpecificPrimaryTripI/OpackIS220PTURH1AorIS220PTURH1B
withterminalboard(accessory)IS200TRPAH1A
• MarkVIeSTurbineSpecificPrimaryTripI/OpackIS220YTURS1AorIS220YTURS1B
‡
withterminalboard(accessory)IS200TRPAS1A
Note‡
ContactGEforhardwareavailability.
3.18.1 ElectricalCharacteristics
Item Min Nominal Max Units
PowerSupply
Voltage 27.4 28.0 28.6 Vdc
Current — — 0.41 Adc
VoltageDetectionInputs(TRPA)
Voltage 16 — 140 Vdc
E-stopInput(TRPA)
Voltage 18 — 140 Vdc
SpeedInputs(TRPA)
Voltage -15 — 15 Vdc
E-stopPowerOutput
Voltage(O.C.) — 28 — Vdc
Current(S.C.) — 17 — mAdc
ContactOut(TRPA)
Voltage — 24 28 Vdc
Current — — 7 Adc
