PCB/EURO card format acc. to DIN 41494 (100 x 160 mm) Width: 30,0 mm (6 TE) Height: 128,4 mm (3 HE) Length: 160,0 mm Net weight: app. 320 g Gross weight: app. 450 g incl. standard export packing Packing volume: app. 2,5 dm3 Space requirements: 14 modules (28 channels) fit into each 19“ rack Requirements on configuration PC: Configuration of modules is made via the RS 232 interface on the module front or via the RS 485 bus by means of a computer (laptop) with the following minimum specifications: Processor: 486 DX, 33 MHz Interfaces: one free RS 232 interface (COM 1 or COM 2) with FIFO type 156550 UART Capacity of fixed disk: min. 5 MB Required working memory: min. 620 KB Operating system: MS DOS Version 6.22 or higher or WIN® 95/98 or NT 4.0

MMS 6210 Dual Channel Shaft Displacement Monitor…………...……......................................................... 9100 – 00002 MMS 6910 W Operating accessories ................................................................................................................9510 – 00001 consisting of: operating and installation manual, configuration software and various connection cables The F48M mating connector has to be ordered separately depending on the intended wiring technology.
