Bently Nevada 3500/92-03-01-00 136188-01 Ethernet/RS232 ModbusI/O Module

short description:

Item no: 3500/92-03-01-00 136188-01

brand: Bently Nevada

Delivery time: In Stock

Payment: T/T

shipping port: xiamen

price:$475


Product Detail

Product Tags

Description

Manufacture Bently Nevada
Model 3500/92-03-01-00
Ordering information 136188-01
Catalog 3500
Description Bently Nevada 3500/92-03-01-00 136188-01 Ethernet/RS232 ModbusI/O Module
Origin United States (US)
HS Code 85389091
Dimension 16cm*16cm*12cm
Weight 0.8kg

Details

Description
The 3500/92 Communication Gateway module provides extensive communication capabilities of all rack monitored values and statuses for integration with process control and other automation systems using both Ethernet TCP/IP and serial (RS232/RS422/RS485) communications capabilities. It also permits Ethernet communications with 3500 Rack Configuration Software and Data Acquisition Software.
Supported protocols include:

Modicon Modbus protocol (via serial communications)

Modbus/TCP protocol (a variant of serial Modbus used for TCP/IP Ethernet communications)

Proprietary Bently Nevada protocol (for communication with 3500 Rack Configuration and Data Acquisition Software packages)
The Ethernet connection to the 3500/92 is an RJ45 connection for 10BASE-T star configuration Ethernet networks.
The 3500/92 supports the communication interfaces, communication protocols, and other features from the original 3500/90 with the exception of the primary value Modbus registers. The 3500/92 now has a Configurable Modbus Register Utility, which can provide the same functionality originally addressed by the primary value Modbus registers.
